Machining Capabilities
Our Warren, Ohio location machine shop boasts 60,000 square feet of space to house 25, medium-sized horizontal, and vertical machining centers. This shop allows us to be more diversified in our machine capabilities, we are more efficient with our precision/smaller machine parts thanks to our Warren facility.
- 79” Vertical Travel
- 118” Horizontal Travel
- 51” Column Travel
- 27 ½ spindle travel, very versatile
- The latest 15M Fanuc controls
- 71” x 63” built-in turn table enabling machining of all sides of part
- Capable of milling, interpolation and profile milling
- 11 ton Table load capacity
- Automatic tool changer with 40 tools
- Chip conveyors
- 21” Vertical Travel
- 118” Horizontal Travel
- 51” Cross Travel
- Profile milling any shapes and sizes
- Double Column Gantry Mill
- Automatic tool changer with 32 tools
- 11,023 lbs. Load capacity
- Chip conveyor
- Very rigid cutting
- 155” Horizontal Travel
- 90” Vertical Travel
- 28” Spindle Travel
- 60” Column Travel
- Tosnuc controls
- 55,000 lbs. Table Capacity
- Mazak T2 control
- 60 Horsepower
- Maximum spindle speed – 300 RPM
- Maximum work piece height – 72”
- Maximum weight capacity – 26,460
- Table diameter – 65”
- Swing 79”
- Automatic tool changer with 16 pocket tools
- Cat 50 vertical
- Mazak T-32 control
- Capable of turning, grooving, milling, drilling, tapping
- 80 Horsepower
- Maximum spindle speed – 300 RPM
- Maximum work piece height – 72”
- Maximum weight capacity – 25,000
- Table diameter – 65”
- X Axis head travel – 40” right / 24.2” left
- Z ram travel – 50”
- X axis rapid traverse rate – 470 inches per minute
- Z axis rapid traverse rate – 550 inches per minute
- Position Accuracy: X axis – .001 / Z axis – .001
- Automatic tool changer with 30 pocket tools
- Cat 50 vertical / Cat 40 horizontal
- 2 Pallet Shuttle
- 3 Right Angle Heads
- 30 Horsepower
- 4500 R.P.M. maximum spindle
- Maximum weight capacity – 2,460
- Capable of milling, drilling, tapping, pocketing, slotting
- Programmable Rotary Table
- 2 Pallet Shuttle with (Two) 24.8” x 24.8” tables
- Automatic tool changer with 40 pocket tools
- X axis travel – 39.37”
- Y axis travel – 31 ½”
- Z axis travel – 29.53”
- 29 1 /2” vertical travel
- 102” horizontal travel
- 31” cross travel
- Automatic tool changer with 40 tools
- Tool gauge preceptors
- Conversational program set-up
- Multi-parts set-up
- Capable of milling, circle interpolation and profile milling
- 7,100 ton load capacity
- Table 39 3/8” x 118 1/8”
- Table Travel – 126”
- Spindle Head Cross Travel – 45 ¼”
- Spindle Head Vertical Travel – 23”
- Automatic tool changer with 40 tools
- Mazatrol 640M Control
- 36” maximum diameter swing over the cross slide
- 18” diameter swing over carriage
- 160” center to center length
- 5,300 lbs. Load capacity
- Capable of profile turning
- I.A. programmable
- 38” maximum diameter swing over the cross slide
- 128” maximum center to center length
- Boring Bar capacity with 31” maximum length
- Chuck work load capacity is 2,200 lbs.
- 6,600 lbs. Load capacity between centers
- Automatic tool changer with 30 tools
- 23” maximum work piece diameter
- 60” center to center horizontal length
- Automatic tool changer
- Conversational controls
- Capable of turning, milling, drilling and tapping
- 2,200 lbs. Load capacity
- Mazatrol Cam T-3 control
- 14” diameter swing
- 70” center to center maximum horizontal length
- 15 Tool Turret
- 3,300 lbs. Load capacity
- Mazatrol Cam T-1 controls
- 8” x 20” part capacity
- Used for milling very small parts
- 36” maximum diameter swing
- 193” horizontal center to center length
- Capable of threading
- 32” maximum diameter swing
- 20” maximum diameter swing over the carriage
- 118” horizontal center to center length
- Capable of threading
- 26” maximum diameter swing
- 128” horizontal center to center length
- Capable of threading
- 18” maximum diameter swing
- 150” horizontal center to center length
- Capable of threading
- 30” maximum diameter swing
- 443” Horizontal Travel
- 118” Vertical Travel
- 150 Ton/75 per Load Capacity
- Right Angle Head
- 100 Horsepower
- 39” Ram “W” Quill Travel
- 157” Cross Travel
- 236” Horizontal Travel
- 80” Vertical Travel
- CNC Heavy Duty Rotary Table with B-Axis 2” x 177.2” x 120 Ton Load Cap
- 25’ X Axis Column Travel
- 19’ Y Axis Headstock Travel
- 4’ W Axis Spindle Out Travel
- 5’ Z Axis Ram Travel
- 9’ Z + W Ram + Spindle Travel
- Universal and Angular Milling Heads
- 1600 rpm Revolution
- 6 Axis CNC
- Numeripath 8000 CNC Control
- 20′ Vertical Travel
- 35′ Horizontal Travel
- 14′ Ram & Spindle Travel
- 14′ x 14′ 120 Ton CNC Controlled Rotary Table
- 360° Right Angle Head Attachment
- Contouring Head Attachment
- Renshaw Precision Inspection in Cycle Probe
- CV60 Taper Spindle
- 100hp Spindle Motor
- 6 Axis CNC
- G.E / Fanuc 15 MB CNC Control
- 20′ Vertical Travel
- 44′ Horizontal Travel
- 8′ Ram & Spindle Travel
- 10′ Linear Table Travel
- 14′ x 16′ 120 Ton CNC Controlled Rotary Table
- 360° Right Angle Head Attachment
- CV60 Taper Spindle
- 80hp Spindle Motor
- Twin Head 2Axis CNC Controlled With Live Spindle
- GE / Fanuc 18it Control / Fanuc Servo Motors
- 20′ Table with 22′ 6″ Swing Diameter
- 18′ Under Rail
- Quick Change Modular Tooling System
- 1-33 RPM table Speed With CNC Orientation
- 275 Ton Table Capacity
- Twin Head 2 Axis CNC Controlled
- GE / Fanuc 10 Control
- 14′ Table 16′ Max Part Turn
- 80 Ton Load Capacity
- Right Angle Head
- 75 Horsepower
- 5” Ram “W” Quill Travel
- 112” Cross Travel
- Siemens Sinumerik 84OD SL CNC Controls
- 60 Position Automatic Tool Changer
- CNC Heavy Duty Rotary Table with B-Axis 2” x 177.2” x 120 Ton Load Cap
- 25’ X Axis Column Travel
- 19’ Y Axis Headstock Travel
- 4’ W Axis Spindle Out Travel
- 5’ Z Axis Ram Travel
- 9’ Z + W Ram + Spindle Travel
- Universal and Angular Milling Heads
- 1600 rpm Revolution
- 4 Axis CNC
- Tosnuc 888 Control
- 90″ Vertical Travel
- 180″ Horizontal Travel
- 28″ Spindle Travel
- 70″ x 180″ Table Size – 55,000 Capacity
- Automatic Tool Changer With 38 Tool
- 2500 RPM Spindle
- 360° Right Angle Head / Rotary Table
